Shotcrete machine for bridge repair

2019-05-20 23:12:37

Gaodetce shotcrete/gunite equipment has manufactured gunite machines or called shotcrete machines in various models for concrete construction, concrete repair and bridge repair since 1999. The industrial terminology of spray guns and shotcrete is used to refer to the process of pneumatically placed concrete materials. Gaodetec also produces spray gun batch plants that allow contractors to deliver without ready-mix concrete trucks. The batch plant is used to mix sand (aggregate) and cement on the job site and then transport it to the installed shotcrete. The Gaodetec shotcrete delivers dry material to the nozzle through a gun hose (up to 1,000 feet) and adds water to the nozzle. The airbrusher controls the water content as it is placed on the surface. The water content affects the slump (or fluidity) of the material. Typically, the material is pre-wetted, which reduces dust during mixing. Gaodetec's hoses and nozzles are heavy-duty, rugged and able to withstand the rigors of everyday construction.

shotcrete machine for bridge repair

As a supplier of high-quality concrete shotcrete machines in China, the Gaodetec shotcrete machine is of high quality in terms of production and accessories. As far as we know, sealing plates and steel rotor plates are key components of the spray gun.

shotcrete machine for concrete repair


,shotcrete machine for concrete construction


For steel rotor plates, our hardness can reach 50~60 HRCand rust resistance. The hardness of steel rotor plates of other suppliers is only 35~40 HRC. Sealing plate hardness: 75-80 HRC, Akron wear ≤0.2cm3/1.61KM, working temperature ≥110°C, rubber sheet and metal plate bonding strength ≥3MPa.

China gunite machine for concrete repair



China shotcrete machine for concrete repair


If your project requires our shotcrete, please let us know what is the output and the maximum. The total size you need. If the voltage is different from our voltage, we can also customize the right voltage motor for you. Please visit our website: www.gaodetec.com
