Deliver filter plates to Indonesia client

2019-02-28 09:43:46

Gaodetec deliver 50 pcs filter press with filter plate in Nov 2018.

filter press with filter plate


The filter press uses a special filter medium to apply a certain pressure to the object, so that a mechanical device that oozes out the liquid is a commonly used solid-liquid separation device. It was used in chemical production in the early 18th century and is still widely used in chemical, pharmaceutical, metallurgical, dye, food, brewing, ceramics and environmental protection industries.
The filter plate has stable performance, convenient operation, safety and labor saving; the metal press tube is processed by seamless steel pipe and plastic steel filter plate, which is resistant to high temperature, high pressure and durable.
The hydraulic compression mechanism of the filter press consists of a hydraulic station, a cylinder, a piston, a piston rod, and a Hafland card hydraulic station connected to the pressure plate. The motor, the oil pump and the relief valve are adjusted. Valves, pressure gauges, oil circuits, fuel tanks.
Filtration method: The flow of the filtrate is clearly divided into flow filtration and dark flow filtration. For the clear flow filtration, a water nozzle is arranged on the lower liquid outlet of each filter plate, and the filtrate flows out intuitively from the water nozzle. Under the dark flow filtration, a liquid outlet hole is arranged below each filter plate, and the liquid outlet holes of the plurality of filter plates are connected into one liquid outlet passage, which is discharged by a pipe connected by the liquid outlet hole below the thrust plate.
If you also want to change the filter plates for your filter press, send your inquiry to info@gaodetec.comAnd please send your filter plates drawing to us for confirm.
If don’t have the plates drawing, please tell us your filter press information to us for reference, and measuring the plate size as the following photos show:

filter plates to Indonesia



Deliver filter plates
